DH-HAC-ME1200BP 2MP HDCVI MotionEye Camera

DH-HAC-ME1200BP Specification:

Camera

Image Sensor 1/2.7″ CMOS

Effective Pixels 1920(H)×1080(V), 2MP

Scanning System Progressive

Electronic Shutter Speed PAL: 1/4~1/100000s

NTSC: 1/3~1/100000s

Minimum Illumination 0.02Lux/F2.0(Color), 30IRE, 0Lux IR on

S/N Ratio More than 65dB

IR Distance Up to 20m (66feet)

IR On/Off Control Auto / Manual

IR LEDs 1

Lens

Lens Type Fixed lens / Fixed iris

Mount Type Board-in

Focal Length 2.8mm

Max Aperture F2.0

Angle of View H: 112°

Focus Control N/A

Close Focus Distance 500mm

19.7”

DORI Distance

Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.

DORI

Definition

Distance

Detect 25px/m

(8px/ft)

2.8mm: 40m(131ft)

Observe 63px/m

(19px/ft)

2.8mm: 16m(52ft)

Recognize 125px/m

(38px/ft)

2.8mm: 8m(26ft)

Identify 250ppm

(76px/ft)

2.8mm: 4m(13ft)

Pan / Tilt / Rotation

Pan/Tilt/Rotation Pan: 0° ~ 360°

Tilt: 0° ~ 90°

Rotation: 0° ~ 360°

Video

Resolution 1080P (1920×1080)

Frame Rate 25/30fps@1080P, 25/30/50/60fps@720P

Video Output 1-channel BNC high definition video output / CVBS

video output (Can switch)

Day/Night Auto (ICR) / Manual

OSD Menu Multi-language

BLC Mode BLC / HLC / DWDR

WDR DWDR

Gain Control AGC

Noise Reduction 2D

White Balance Auto / Manual

Smart IR Auto / Manual

PIR

Detection Passive infrared

Detection Range 10m, 110°

Alarm prompt Red led

Installation height Default bracket, wall mount, 2.2-2.5m

Certifications

Certifications CE (EN55032, EN55024, EN50130-4)

FCC (CFR 47 FCC Part 15 subpart B, ANSI C63.4-2014)

UL (UL60950-1+CAN/CSA C22.2 No.60950-1)

Interface

Audio Interface N/A

Electrical

Power Supply 12V DC ±30%

Power Consumption Max 4.1W (12V DC, IR on)

Environmental

Operating Conditions -10°C ~ +50°C (+14°F ~ +122°F) / Less than 95% RH

* Startup should be done at above -10°C (14°F)

Storage Conditions -10°C ~ +50°C (+14°F ~ +122°F) / Less than 95% RH

Ingress Protection &Vandal Resistance IP67

Construction

Casing Aluminum (Front cover) + Plastic (Rear Barrel)

Dimensions 146.6mm×72.4mm×83mm (5.77″×2.85″×3.27″)

Net Weight 0.23kg (0.51lb)

Gross Weight 0.30kg (0.66lb)
