System

Main Processor Embedded Processor

Operating System Embedded LINUX

Video and Audio

Analog Camera Input 4/8 Channel, BNC

HDCVI Camera 1080P@25/30fps, 720P@25/30fps

AHD Camera 1080P@25/30, 720P@25/30fps

TVI Camera 1080P@25/30, 720P@25/30fps

CVBS Camera PAL/NTSC

IP Camera Input

4CH: 4+1, each channel up to 2MP

8CH: 8+2, each channel up to 5MP

Audio In/Out 1/1, RCA

Two-way Talk Reuse audio in/out, RCA

Recording Video Compression

H.264

Resolution 1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF

Record Rate Main Stream:

4CH: All channel 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF(1~25/30fps)

8CH: the 1st channel 1080N/720P(1~25/30fps), others 1080N(1~12fps)/720P(1~15fps); 960H/D1/HD1/BCIF/CIF/QCIF(1~25/30fps)

Sub steram: 4CH: CIF/QCIF (1~15fps) 8CH: CIF/QCIF (1~7fps) Video Bit Rate 32Kbps ~ 4096Kbps Per Channel

Record Mode Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop

Record Interval

1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec

Audio Compression

AAC(only for the 1st channel), G.711A, G.711U, PCM

Audio Sample Rate

8KHz, 16 bit Per Channel

Audio Bit Rate

64Kbps Per Channel

Display

Interface 1 HDMI ,1 VGA

Resolution 1920×1080, 1280×1024, 1280×720, 1024x768

Multi-screen Display When IP extension mode not enabled:

4CH: 1/4

8CH: 1/4/8/9

When IP extension mode enabled:

4CH: 1/4/6

8CH: 1/4/8/9/16

OSD

Camera title, Time, Video loss, Camera lock, Motion detection, Recording

Network

Interface

1 RJ-45 Port (100M) Network Function

HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter ,DDNS, FTP, Alarm Server, P2P,IP Search (Supports IP camera, DVR, NVS, etc.)

Max. User Access 128 users

Smart Phone iPhone, iPad, Android

Interoperability ONVIF 16.12, CGI Conformant

Video Detection and Alarm

Trigger Events

Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips

Video Detection

Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis

Alarm input N/A

Relay Output N/A

Playback and Backup

Playback 4CH: 1/4 8CH: 1/4/9

Search Mode

Time /Date, Alarm, MD and Exact Search (accurate to second)

Playback Function

Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom

Backup Mode USB Device/Network

Storage

Internal HDD 1 SATA Port, up to 6TB capacity

eSATA N/A

Auxiliary Interface

USB 2 USB 2.0

RS232 N/A

RS485 N/A

Electrical

Power Supply DC12V/1.5A

Power Consumption

(Without HDD) <10W
