System

Main Processor Embedded Processor

Operating System Embedded LINUX

Video and Audio

Analog Camera Input 32 Channel, BNC

HDCVI Camera 5MP, 4MP, 1080P@25/30fps, 720P@50/60fps, 720P@25/30fps

AHD Camera 5MP, 4MP, 1080P@25/30, 720P@25/30fps

TVI Camera 5MP, 4MP, 1080P@25/30, 720P@25/30fps

CVBS Camera PAL/NTSC

IP Camera Input 32 Channel, each channel up to 8MP

Audio In/Out 4/1, BNC

Two-way Talk 1 Mic In, 1 Mic Out, BNC

Recording

Compression H.265+/H.265/H.264+/H.264

Resolution 5M-N, 4M-N, 1080P, 1080N, 720P, 960H, D1, CIF

Record Rate Main stream:the 1st & 2nd channel 5M-N（1~10fps）, others 4M-N/1080P(1~15fps); 1080N/720P/960H/

D1/CIF (1~25/30fps)

Sub steram: D1/CIF(1~15fps)

Bit Rate 32Kbps ~ 6144Kbps Per Channel

Record Mode Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop

Record Interval 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec

Audio Compression AAC(only for the 1st channel), G.711A, G.711U, PCM

Audio Sample Rate 8KHz, 16 bit Per Channel

Audio Bit Rate 64Kbps Per Channel

Display

Interface 2 HDMI ,1 VGA, 1 TV

Resolution HDMI 1:3840×2160, 2560×1440, 1920×1080, 1280×1024, 1280×720

HDMI 2 / VGA: 1920×1080, 1280×1024, 1280×7201920×1080, 1280×1024, 1280×720

Multi-screen Display 1/4/8/9/16/25/36

OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording

Network

Interface 1 RJ-45 Port (1000M)

Network Function HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, SNMP, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Supports Dahua IP camera, DVR, NVS, etc.)

Max. User Access 128 users

Smart Phone iPhone, iPad, Android

Interoperability ONVIF 16.12, CGI Conformant

Video Detection and Alarm

Trigger Events Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips

Video Detection Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis

Alarm input 16

Relay Output 6

Playback and Backup

Playback 1/4/9/16

Search Mode Time /Date, Alarm, MD and Exact Search (accurate to second)

Playback Function Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom

Backup Mode USB Device/Network

Storage

Internal HDD 4 SATA Ports, up to 10TB capacity

eSATA 1 Port

Auxiliary Interface

USB 1 USB 2.0, 2 USB 3.0

RS232 1 port, for PC communication & Keyboard

RS485 1 Port, for PTZ Control

RS422 1 Port, for PTZ Control

Electrical

Power Supply AC100V-240V, 50/60Hz

Power Consumption

(Without HDD)

<35W

Construction

Dimensions 1.5U, 440mm×417mm×76mm (17.3″x 16.4″ x 3.0″)

Net Weight

(Without HDD)

5kg (11.0lb)

Gross Weight 7kg (15.43lb)

Installation Desktop installation/Rack-mounted

Environmental

Operating Conditions -10°C ~ +55°C (+14°F ~ +131°F), 10%~ 90% RH

Storage Conditions -20°C ~ +70°C (-4°F ~ +158°F) , 0~ 90% RH

Third-party Support

Third-party Support Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more

Certifications

Certifications FCC: Part 15 Subpart B

CE: CE-LVD: EN 60950-1/IEC 60950-1

CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024

UL: UL 60950-1
