Camera

Image Sensor 1 MP CMOS Image Sensor

Signal System PAL/NTSC

Effective Pixels 1296 (H) ×732 (V)

Min. illumination 0.1 Lux@(F1.2,AGC ON), 0 Lux with IR

Shutter Time 1/25 (1/30) s to 1/50,000 s

Lens

3.6 mm (6 mm, 8 mm, 12 mm, 16 mm optional)

Field of view: 70.9°(3.6 mm), 56.7°(6 mm), 38.6°(8 mm), 27.5°(12 mm), 17.7°(16 mm)

Lens Mount M12

Day & Night ICR

Angle Adjustment Pan: 0 to 360°, Tilt: 0 to 180°, Rotation: 0 to 360°

Synchronization Internal synchronization

Video Frame Rate 720p@25fps/720p@30fps

HD Video Output 1 analog HD output

S/N Ratio >62dB

General

Operating Conditions -40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)

Power Supply 12 V DC±15%

Power Consumption Max. 5 W

Protection Level IP66

IR Range Up to 80 m

Dimensions 86.7 mm × 81.6 mm × 226 mm(3.4" × 3.2" × 8.9")

Weight 700 g (1.54 lb.)
