Camera

Image Sensor 1 MP CMOS image sensor

Signal System PAL/NTSC

Effective Pixels 1296 (H) × 732 (V)

Min. illumination 0.1 Lux@(F1.2,AGC ON), 0 Lux with IR

Shutter Time 1/25 (1/30) s to 1/50,000 s

Lens

2.8 mm, 3.6 mm, 6 mm optional

Field of view: 70.9°(3.6 mm), 92°(2.8 mm), 56.7°(6 mm)

Lens Mount M12

Day & Night ICR

Angle Adjustment Pan: 0°to 360°, Tilt: 0°to 75°, Rotation: 0°to 360°

Synchronization Internal synchronization

Video Frame Rate 720p@25fps/720p@30fps

HD Video Output 1 analog HD output

S/N Ratio >62 dB

General

Operating Conditions -40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)

Power Supply 12 V DC±15%

Power Consumption Max. 4 W

Protection Level IP66

IR Range Up to 20 m

Dimensions Φ 89.9 × 70.1 mm (3.54" × 2.76")

Weight 280 g (0.62 lb.)
