System Overview

With the surveillance operators pursuing to HD/UHD which further adds the

storage and transmission cost, HDCVI H.265+/H.265 has been released to

incredibly decrease the required bitrate while ensuring the video quality in

realizing high resolution surveillance such as 4MP/4K.

The Lite Series is designed for high cost performance and quality. The range

offers a great solution for users facing budget constraints who both require

quality and performance. And with the adoption of Smart H.265+/H.265,

the series improves encoding efficiency, saving on bandwidth/storage costs,

and significantly reducing the Total Cost of Ownership (TCO).

Functions

Smart H.265+

Smart Codec, H.265+ can reduce up to 90% bit rate and storage

requirements compared with H.264 without having to invest in new

cameras.

HDCVI/AHD/TVI/CVBS Auto-detect

The XVR can auto recognize the signal of front-camera without any setting.

It makes operation more friendly and convenient.

High Definition Camera Input

The XVR supports up to 5MP HDCVI camera and 6MP IP camera input.

Coaxial Audio/Upgrade/Alarm

The integrated design can reduce wiring troubles which makes it much more

cost-effective and convenient for installation.

Long Distance Transmission

The HDCVI system supports long distance transmission over coaxial cable

and UTP, max. 700m for 4K/4MP, 800m for 1080P and 1200m for 720P.

Smart Fan Design

The smart fan can automatically turn on or turn off according to the

CPU temperature. This function can effectively reduce the fan noise to

provide a better user experience.

Intelligent Video System (IVS)

With built-in intelligent video analytics, the XVR has the ability to detect

and analyze moving objects for improved video surveillance. The XVR

provides optional standard intelligence at the edge allowing detection of

multiple object behaviors such as abandoned or missing objects. IVS also

supports Tripwire analytics, allowing the camera to detect when a predetermined line has been crossed.

Face Detection

It is a typical technology being used in a variety of applications for

searching or identification of individuals.

Smart Search

This function helps you get more motion detect video during a short

time through drawing a region when playback. It is very useful when an

emergency occurs.
