System

Main Processor Dual-core embedded processor

Operating System Embedded LINUX

Audio and Video

IP Camera Input 4 Channel

Two-way Talk 1 Channel Input, 1 Channel Output, RCA

Display

Interface 1 HDMI, 1 VGA

Resolution HDMI: 3840 ×2160,1920×1080, 1280×1024, 1280×720, 1024×768

VGA: 1920×1080, 1280×1024, 1280×720, 1024×768

Decoding Capacity 1ch@8MP 30fps, 4ch@1080P 30fps

Multi-screen Display 1/4

OSD Camera title, Time, Camera lock, Motion detection, Recording

Recording

Compression H.265+/H.264+

Resolution 8MP/6MP/5MP/4MP/3MP/1080P/ 720P/ D1&etc.

Record Rate 80Mbps

Bit Rate 16Kbps ~ 20Mbps Per Channel

Record Mode Manual, Schedule(Regular(Continuous), MD, Stop

Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec

Video Detection and Alarm

Trigger Events Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips

Video Detection Motion Detection, MD Zones: 396 (22 × 18),

and Tampering

Alarm input N/A

Relay Output N/A

Playback and Backup

Sync Playback 1/4

Search Mode Time /Date, MD and Exact Search

(accurate to second)

Playback Function Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom

Backup Mode USB Device/Network

Third-party Support

Third-party Support Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more

Network

Interface 1 RJ-45 port (10/100Mbps)

Ethernet Port 1 Independent 100Mbps Ethernet Port

PoE 4 ports (IEEE802.3at/af)

Network Function HTTP/HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, DDNS, IP Search(Support Dahua IP camera, DVR, NVS and etc.), P2P

Optical Fiber Interface N/A

Max. User Access 128 users

Smart Phone iPhone, iPad, Android

Interoperability ONVIF ,SDK, CGI Conformant

Storage

Internal HDD 1 SATA III Port, up to 6TB capacity for each HDD

HDD Mode Single

eSATA N/A

Auxiliary Interface

USB 2 ports (1 Rear USB2.0, 1 Front USB2.0)

RS232 N/A

RS485 N/A

Electrical

Power Supply Single, DC48V/1.25A

Power Consumption NVR: <6W (without HDD)

PoE: Max 25.5w for single port, 50w in total

Environmental

Operating Conditions -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa

Storage Conditions -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH

Construction

Dimensions(W×D×H) Compact 1U, 260mm×229.3mm×47.6mm

(10.2″ x 9.03″ x 1.9″)

Net Weight 0.86kg (1.89 lb) (without HDD)

Gross Weight 1.87kg(4.12 lb)(without HDD)

Certifications

CE EN55032, EN55024, EN50130-4, EN60950-1

FCC Part 15 Subpart B, ANSI C63.4-2014
