Camera

Image Sensor 5 MP CMOS image sensor

Max. Resolution 2560 (H) × 1944 (V)

Min. Illumination Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR

Shutter Time PAL: 1/25 s to 1/50, 000 s,NTSC: 1/30 s to 1/50, 000 s

Day & Night IR cut filter

Angle Adjustment Pan: 0° to 360°; Tilt: 0° to 180°; Rotate: 0° to 360°

Lens Lens Type

2.8 mm, 3.6 mm, 6 mm, 8 mm, 12 mm fixed lens

Focal Length & FOV

85.5° (2.8 mm), 80.1° (3.6 mm), 57.1° (6 mm), 41° (8 mm), 25.7° (12 mm)

Lens Mount M12


Image Settings Brightness, Sharpness, DNR, Mirror, Smart IR

Frame Rate PAL: 5 MP@20fps, 4 MP@25fps, 1080p@25fps,NTSC: 5 MP@20fps, 4 MP@30fps, 1080p@30fps

Day/Night Mode Auto/Color/BW (Black and White)

Wide Dynamic Range (WDR) DWDR

Image Enhancement

BLC

White Balance

ATW/MWB

AGC

Support

Interface

Video Output

Switchable TVI/AHD/CVI/CVBS

General

Material

Front cover: Metal,Main body: Plastic

Dimension

86.7 mm × 81.6 mm × 226 mm (3.41" × 3.23" × 8.67")

Weight

Approx. 680 g (1.5 lb.)

Operating Condition

-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)

Communication

Up the coax, Protocol: HIKVISION-C (TVI output)

Language English

Power Supply 12 VDC ±25%

Consumption

Max. 4.3 W

IR Range

Up to 40 m

Approval

Protection IP67
