CAMERA

Image Sensor 1/2.8″ CMOS

Effective Pixels 1920(H)×1080(V), 2MP

Scanning System Progressive

Electronic Shutter Speed PAL: 1/25~1/100000s

NTSC: 1/30~1/100000s

Minimum Illumination 0.005Lux/F1.6, 30IRE, 0Lux IR on

S/N Ratio More than 65dB

IR Distance Up to 40m (131feet)

IR On/Off Control Auto / Manual

IR LEDs 2

Lens

Lens Type Fixed lens / Fixed iris

Mount Type Board-in

Focal Length 3.6mm (2.8mm, 6mm Optional)

Max Aperture F1.6

Angle of View H: 86.9° (106.0°/52.9°)

Focus Control N/A

Close Focus Distance 1200mm (600mm/2400mm)

47.2” (23.6”/94.5”)

Detect 25px/m

(8px/ft)

2.8mm: 39m(127ft)

3.6mm: 55m(181ft)

6mm: 83m(272ft)

Observe 63px/m

(19px/ft)

2.8mm: 15m(51ft)

3.6mm: 22m(73ft)

6mm:33m(109ft)

Recognize 125px/m

(38px/ft)

2.8mm: 8m(25ft)

3.6mm: 11m(36ft)

6mm: 17m(54ft)

Identify 250ppm

(76px/ft)

2.8mm: 4m(13ft)

3.6mm: 6m(18ft)

6mm: 8m(27ft)

Pan / Tilt / Rotation

Pan/Tilt/Rotation Pan: 0° ~ 360°

Tilt: 0° ~ 90°

Rotation: 0° ~ 360°

Video

Resolution 1080P (1920×1080)

Frame Rate 25/30fps@1080P, 25/30/50/60fps@720P

Video Output 1-channel BNC high definition video output / CVBS video output (Can switch)

Day/Night Auto (ICR) / Manual

OSD Menu Multi-language

BLC Mode BLC / HLC / DWDR

WDR DWDR

Gain Control AGC

Noise Reduction 2D

White Balance Auto / Manual

Smart IR Auto / Manual

Certifications

Certifications CE (EN55032, EN55024, EN50130-4)

FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)

UL (UL60950-1+CAN/CSA C22.2 No.60950-1)

Interface

Audio Interface N/A

Eelectrical

Power Supply 12V DC ±30%

Power Consumption Max 3.0W (12V DC, IR on)

Environmental

Operating Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH

* Start up should be done at above -40°C (-40°F)

Storage Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH

Ingress Protection & Vandal Resistance IP67

Construction

Casing Plastic

Dimensions 198.9mm×80.2mm×76.2mm (7.83″×3.16″×3.00″)

Net Weight 0.22kg (0.49lb)

Gross Weight 0.36kg (0.79lb)
