Camera

Image Sensor 1/3” 4Megapixel progresive CMOS

Effective Pixels 2560(H)x1440(V)

RAM/ROM 256MB/16MB

Scanning System Progressive

Minimum Illumination 0.09Lux/F2.0( Color,1/3s,30IRE)

0.5Lux/F2.0( Color,1/30s,30IRE)

0Lux/F2.0(IR on)

S/N Ratio More than 50dB

IR Distance Distance up to 30m(98ft)

IR On/Off Control Auto/ Manual

IR LEDs 1

Lens

Lens Type Fixed

Mount Type Board-in

Focal Length 2.8 mm (3.6 mm optional)

Max. Aperture F2.0/F2.0

Angle of View H:101°/80°, V:54°/44°

Focus Control Fixed

Close Focus Distance 0.8m(2.63ft)

DORI Distance Lens Detect Observe Recognize Identify

2.8 mm 56m(184ft) 22.4m(73.5ft) 11.2m(36.7ft) 5.6m(18.4ft)

3.6 mm 80m(262.5ft) 32m(105ft) 16m(52.5ft) 8m(26.3ft)

PTZ

Pan/Tilt Range Pan:0° ~360° ;Tilt:0° ~90° ;Rotation:0° ~360°

Intelligence

Event Trigger Motion detection, Video tampering , Network disconnection , Scene change, IP address conflict, Illegal Access,Storage anomaly

Video

Compression H.265/H.264/H.264B/MJPEG(Sub Stream)

Smart Codec Support H.265+/H.264+

Streaming Capability 2 Streams

Resolution 4M(2560×1440)/3M(2304×1296)/1080P(1920×1080)/720P(1280×720)/VGA(640×480)/D1(704×576/704×480)/CIF(352×288/352×240)

Frame Rate Main Stream: 4M(1 ~ 20fps)

Sub Stream: D1(1 ~ 25/30fps)

Bit Rate Control CBR/VBR

Bit Rate H.264: 32K~6144K

H.265: 12K~ 6144K

Day/Night Auto(ICR) / Color / B/W

BLC Mode BLC / HLC / DWDR
